Fully-sealed optical engine
Super fine picture quality
The fully-sealed optical engine adopts a high-definition optical lens featuring excellent light transmission, projecting clearer images with high colour accuracy to reproduce the true artistic beauty of films.
400 ISO lumens for true brightness
With ISO standard effective luminous flux certification, it boasts a brightness of up to 400 ISO lumens, ensuring accurate brightness representation and more visible details.
1080p physical resolution
Compact size and high-definition
Adopts 1080p HD resolution with fine picture quality and true colour output. Supports 4K video playback with even more details.
120-inch ultra-wide screen
Immersive giant screen for your enjoyment
With a 1.21:1 throw ratio, you can project a large screen ranging from 40 to 120 inches wherever you are.
High-performance processor
Seamless experience
Featuring an MT9630 high-performance chip with 2GB + 16GB large storage, it delivers powerful performance to meet your various needs, ensuring uninterrupted entertainment.
Bluetooth remote control
Control the projector more freely
The Bluetooth remote control covers a comprehensive 360° with almost no blind spots. Access your favourite content in an instant with shortcuts.
Technical specifications:
Basic Information:
- Items Dimensions: 210 × 128 × 189 mm
- Weight: 2.0 kg
Display:
- Display Technology: LCD
- Brightness: 400 ANSI Lumens
- Resolution: 1920 × 1080P
- Throw Ratio: 1.21 : 1
- Screen Dimensions: 40″~120″ (Recommend: 60″-100″)
- Lens Focus: Auto Focus
- Keystone Correction: Auto Keystone Correction
- Auto Obstacle Avoidance: Support
- Auto Screen Alignment: Support
- Projection Method: Forward, Side, Hoisting (15°)
Hardware:
- Processor: MT9630 high-performance chip platform
- Built-in Storage: 2 GB DDR3/16 GB eMMC
System:
- System: Android TV™ OS
- Mirroring Display: Google Cast
- Bluetooth: Bluetooth 5.0
- Wireless Connectivity: Wi-Fi IEEE 802.11 a/b/g/n/ac 2.4GHz/5GHz
Speaker & Audio:
- Audio Effects: Dolby Audio
- Speaker: 5W full-range × 2
Electrical:
- Rated power: ≤ 120.0 W
- Standby Power: ≤ 0.50W
- Auto power off: Support
- Input: 19.0 V ⎓ 6.32 A
- Noise: ≤ 30 dB(A) (Theater mode at an ambient temperature of 25°C)
Storage and Operating Conditions:
- Storage Temperature/Humidity: -20℃ to 55℃ ≤ 90%RH
- Operating Temperature/Humidity: 0℃ to 40℃ / 20%RH–80%RH
Items included:
- Projector x1
- Remote Control x1
- Power Adapter x1
- Power Cable x1
- User Manual
- Warranty Notice
- Desiccants
